Carinya Select Bi-Fold Window & Door
RESIDENTIAL

A premium solution for those seeking superior functionality and style in the alfresco area of their home.
The Carinya Select Top and Bottom Bi-Fold System features flat sill options for smooth accessibility and optional mid rails with multi-point locking in a range of opening configurations.
For a modern designer look, the Carinya Bi-Fold extrusions are a consistent 85mm wide face on both the stiles and rails. This allows a balanced visual face and
allows a vast array of hardware lock options. Combined with commercial grade spigots, these door panels are superior in strength and performance.
The Bottom rolling Bi-Fold system features the innovative F2/F3 Centor Bottom rolling hardware which overcomes the requirement for any structural beam as
needed in a top hung Bi Fold system. This is ideal for the new or renovation market that want an Alfresco style opening without the additional cost of a structural
beam.
The Top rolling Bi-Fold system features the Alspec commercial grade E2A Centor rolling hardware which has been used and proven over time in commercial
projects. This is ideal for the new construction market that want an Alfresco style opening.
The Carinya attention to detail includes concealed flush bolt brackets, reducing visible fixings, as well as custom extrusion design allowing for clean interaction with
door hardware. The Centor hardware is of the highest quality which is backed by a 10 year warranty.

Specifications
• Maximum Panel Height: 2400mm
• Maximum Panel Width: 900mm
• Maximum Glass Thickness: 10.5mm or 24mm IGU
• Maximum Panel Weight: 40kg (F2 & E2A) 80kg (F3)
• 92mm Frame
Application
• Renovation Market
• New Residential Construction
• Window Replacement and Renovation
• Low-Rise Multi-Unit Developments
• Aged Care and Wheelchair Requirements
Options
• A range of sill options for water or recessed openings.
• A range of fixed light options including glass louvres.
• Retractable screening options for insect protection.

Hardware
The Carinya Select Bi-Fold Door has been designed with hardware from the start, not as an after thought. All locks and flush bolts blend seamlessly with the custom
extrusion for a professional finish.
The sashes feature a commercial door spigot, allowing a strong and robust panel for enduring use making the panel free of twist and movement.
Standard lock hardware options include Brio’s lever furniture, combined with Lockwood’s proven Optimum mortice lock. Fitting snug within the stile and allowing
an extended backset, this lock removes the common issue of minimal key distance to the jamb. Other lock options include commercial locksets and furniture for a
complete choice.
Custom flush bolt guides have been designed to remove visible fixings from the extrusion faces, allowing a tighter integrated sealing saving potential energy costs
while giving a professional, uninterrupted clean visible surface.
